SDR Platform for Production Test Equipment - SAPT-100
SIGALGO SaPT-100 is a Base Station - BTS - emulator for use in a Production Test Environment. The SaPT is a key part of the Automated Test Environment for the production of Remote Radio Heads - RRHs. The SaPT-100 is available for 3G and 4G air interfaces and can be customised to meet our customers' specific test requirements. The default configuration is with 4Tx/4Rx allowing either 2 2x2 RRH or 1 4x4 RRH to be tested at the same time. The Digital interface is customised to match our customers specific I&Q mapping interface.
Optical and Management Interfaces
- Up to 6Gbps Line Rate Fibre
- Number of SFP: 2
- CPRI V1.2 - V4.2 REC support @ 1228.8Mbit/s, 2457.6Mbit/s, 3072Mbit/sec, 4915.2Mbit/s & 6144Mbit/s rates
- Up to 8 configurable IQ carriers
- Individual complex gain control of each carrier
- Configurable mapping of IQ signal data to CPRI IQ stream
- Configurable IDLE patterns
- Loadable IQ signal data in text files
- Configurable VSS support
- Web interface
- Status
- Configuration
- Loading/Saving uplink RF signals and downlink fibre signals
- Export of IQ captures from uplink fibre and downlink RF
- Simple capture analysis (waveform display, FFT analysis, I vs Q plots)
- Control
- Firmware management
- Text based command interface via TCP socket
- SCPI interface (optional)
